5 HP Industrial Cabinet Saw with 52" T-Glide Fence Assembly - ICS51230-52

5 HP Industrial Cabinet Saw with 52" T-Glide Fence Assembly - ICS51230-52

$5,940.00
Skip to product information
5 HP Industrial Cabinet Saw with 52" T-Glide Fence Assembly - ICS51230-52
5 HP Industrial Cabinet Saw with 52" T-Glide Fence Assembly - ICS51230-52
10520

5 HP Industrial Cabinet Saw with 52" T-Glide Fence Assembly - ICS51230-52 - Default Title

$5,940.00
Out of stock

The SawStop® Industrial Cabinet Saw is the definition of industrial grade. It is the heaviest, most powerful and highest-quality 10″ cabinet saw available. The Industrial T-Glide Fence Assembly offers the durability, versatility, and the peace of mind only SawStop’s patented safety system can provide.

More Details

Features

  • 52-INCH T-GLIDE FENCE ASSEMBLY: 52" Industrial T-Glide Fence System provides smooth operation, an expansive work surface, precision measurement and sure lockdown without deflection.
  • EXPANSIVE TABLE: Larger, heavier tabletop provides an extensive cutting surface
  • DUST COLLECTION: 99% dust collection is delivered above the table with the included dust collection blade guard, and below the table with advanced shrouding around the blade.
  • SAWSTOP SAFETY SYSTEM: Stops a spinning blade on contact with skin. The blade stops in less than 5 milliseconds, and drops below the table, minimizing a potentially life-altering injury to a mere scratch

What’s Included

  • (2) Cast Iron Extension Wings
  • (1) Miter Gauge
  • (1) Dust Collection Blade Guard
  • (1) Riving Knife
  • (2) Blade Wrenches
  • (1) Push Stick
  • (1) 10” Blade
  • (1) Standard Lockdown Insert
  • (1) Standard Brake Cartridge
  • (1) Owner’s Manual
  • (2) Hardware Packs
  • (1) 3mm Hex Key
  • (1) 5mm Hex Key
  • (1) 8mm Hex Key
  • (1) Blade Spacing Adjustment Gauge

Complimentary Products

Product Details

The SawStop® Industrial Cabinet Saw is the definition of industrial grade. It is the heaviest, most powerful and highest-quality 10″ cabinet saw available. The Industrial T-Glide Fence Assembly offers the durability, versatility, and the peace of mind only SawStop’s patented safety system can provide.

What’s Included

  • (2) Cast Iron Extension Wings
  • (1) Miter Gauge
  • (1) Dust Collection Blade Guard
  • (1) Riving Knife
  • (2) Blade Wrenches
  • (1) Push Stick
  • (1) 10” Blade
  • (1) Standard Lockdown Insert
  • (1) Standard Brake Cartridge
  • (1) Owner’s Manual
  • (2) Hardware Packs
  • (1) 3mm Hex Key
  • (1) 5mm Hex Key
  • (1) 8mm Hex Key
  • (1) Blade Spacing Adjustment Gauge

Specifications

  • Motor: 5 HP (60Hz) | 1 phase, 230v, 19.7 A
  • Saw body footprint: 20" W x 25" D (Cabinet)
  • Overall dimensions: 85 1/4" W x 36 1/2" D x 34" H
  • Cast-iron table: 24" W x 30" D
  • Extension wings: 10" W x 30" D each
  • Shipping weight (approx.): 640 lbs. without fence.
  • Shipping weight (approx.): 685 lbs. with fence.
  • Blade: 10" diameter 40-tooth Titanium, 5/8" arbor
  • Blade tilt: Left
  • Maximum depth of cut at 0°: 3-1/8"
  • Maximum depth of cut at 45°: 2-1/4"
  • Dado diameter: 8"
  • Dado max. width: 29/32"
  • Dust-collection port: 4" diameter
  • Insert: zero clearance, phenolic core, melamine surfaces
  • Blade guard: (dust collection) port diameter 1-1/2" Outside, 1-1/4" Inside
  • Riving knife/splitter: 0.090" (2.3 mm)

Brand: SawStop
